| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 10150mm | ||
| Width | 2500mm | ||
| Height | 3700mm | ||
| Curb Weight | 17580kg | ||
| Gross Weight | 31000kg | ||
| Seats | 3 | ||
| Max Speed | 77km/h | ||
| Chassis | |||
| Chassis Model | SX5316GJBDT346 | ||
| Front/Rear Overhang | 1525/2050mm | ||
| Number of Leaf Springs | left 14 right 13/left 14 right 13/12,4/4/12,5/5/12,4/4/5,5/5/5,13/13/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3375+1400,1950+3225+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2036/2036mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 20/16° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12R22.5 18PR,11.00-20 18PR,12.00-20 16PR,11.00R20 18PR,12.00R20 16PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.336E40 | Weichai Holding Group Co., Ltd. | 247kW | 9726ml |
| WP12.336E40 | Weichai Holding Group Co., Ltd. | 247kW | 11596ml |
| WP12.375E40 | Weichai Holding Group Co., Ltd. | 276kW | 11596ml |
| ISM11E4 345 | Xi'an Cummins Engine Co., Ltd. | 250kW | 10800ml |
| ISM11E4 385 | Xi'an Cummins Engine Co., Ltd. | 280kW | 10800ml |
