| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national V emission standards, GB3847-2005 | ||
| Length | 8800,8865,9000mm | ||
| Width | 2500mm | ||
| Height | 3980,3750mm | ||
| Curb Weight | 13300kg | ||
| Gross Weight | 13495kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | BJ1139VJPEK-A1 | ||
| Front/Rear Overhang | 1365/2735,1365/2800,1365/2935mm | ||
| Number of Leaf Springs | 8/10+10,9/10+10 | ||
| Number of Axles | 2 | ||
| Wheelbase | 5200,4700mm | ||
| Axle Load | 4050/9445kg | ||
| Front Wheel Track | 1930mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 20/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-20,8.25R20,9.00-20,9.00R20,10R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF3.8s5168 | Beijing Foton Cummins Engine Corporation | 125kW | 3760ml |
