| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national IV emission standards | ||
| Length | 6500mm | ||
| Width | 2380mm | ||
| Height | 3600mm | ||
| Curb Weight | 5700kg | ||
| Gross Weight | 10000kg | ||
| Seats | 3 | ||
| Max Speed | 79km/h | ||
| Chassis | |||
| Chassis Model | CA5100GYYP62K1E4 | ||
| Front/Rear Overhang | 1400/1300mm | ||
| Number of Leaf Springs | 7/7+6,3/7+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4500,4200,4000,3800mm | ||
| Axle Load | 3600/6400kg | ||
| Front Wheel Track | 1774mm | ||
| Rear Wheel Track | 1740mm | ||
| Approaching/Departuring Angle | 15/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25R16,8.25R20(14PR),9R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| BF4M2012-14E4 | China FAW Group Corporation | 106kW | 4040ml |
| BF4M2012-13E4 | China FAW Group Corporation | 99kW | 4040ml |
