| Basic Information | |||
| Usage | Ambulance | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB14762-2008 national Ⅳ emission standards, GB18285-2005,GB11340-2005,GB14763-2005 | ||
| Length | 5926,5930mm | ||
| Width | 1993mm | ||
| Height | 2700,2800mm | ||
| Curb Weight | 3000kg | ||
| Gross Weight | 3550kg | ||
| Seats | 5-9 | ||
| Max Speed | 160km/h | ||
| Chassis | |||
| Chassis Model | Sprinter 324H, Daimler AG | ||
| Front/Rear Overhang | 1021/1240,1021/1244mm | ||
| Number of Leaf Springs | -/2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3665mm | ||
| Axle Load | 1480/2070kg | ||
| Front Wheel Track | 1710mm | ||
| Rear Wheel Track | 1716mm | ||
| Approaching/Departuring Angle | 19/17,19/16.8° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 235/65R16C | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 272979 | Daimler AG | 190kW | 3498ml |
