| Basic Information | |||
| Usage | Ambulance | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 5452,5652mm | ||
| Width | 1972mm | ||
| Height | 2380,2600mm | ||
| Curb Weight | 2587kg | ||
| Gross Weight | 3510kg | ||
| Seats | 7-9 | ||
| Max Speed | 120km/h | ||
| Chassis | |||
| Chassis Model | JX6571T-M6, Jiangling Motors Group Co., Ltd. | ||
| Front/Rear Overhang | 982/900,982/1100mm | ||
| Number of Leaf Springs | -/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3570mm | ||
| Axle Load | 1760/1750kg | ||
| Front Wheel Track | 1692mm | ||
| Rear Wheel Track | 1700mm | ||
| Approaching/Departuring Angle | 22.1/23.7° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 225/65 R16C | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| JX493ZLQ6 | Jiangling Motors Group Co., Ltd. | 85kW | 2771ml |
