| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005( national Ⅳ emission standards), GB3847-2005 | ||
| Length | 8785mm | ||
| Width | 2500mm | ||
| Height | 3700,3040mm | ||
| Curb Weight | 12900kg | ||
| Gross Weight | 14000kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | QL11409NFR | ||
| Front/Rear Overhang | 1335/2450mm | ||
| Number of Leaf Springs | 7/7+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 5000mm | ||
| Axle Load | 4450/9550kg | ||
| Front Wheel Track | 1960mm | ||
| Rear Wheel Track | 1855mm | ||
| Approaching/Departuring Angle | 26/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00-20,9.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4HK1-TCG40 | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 139kW | 5193ml |
