| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB18352.3-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 5295,5895mm | ||
| Width | 1860mm | ||
| Height | 1775,2000,2100,2250mm | ||
| Curb Weight | 2150kg | ||
| Gross Weight | 2810kg | ||
| Seats | 2+3 | ||
| Max Speed | 173km/h | ||
| Chassis | |||
| Chassis Model | JXW1031ASC, Jiangxi ISUZU Engine Co., Ltd. | ||
| Front/Rear Overhang | 905/1295,905/1895mm | ||
| Number of Leaf Springs | -/5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3095mm | ||
| Axle Load | 1235/1575kg | ||
| Front Wheel Track | 1570mm | ||
| Rear Wheel Track | 1570mm | ||
| Approaching/Departuring Angle | 25/21,25/17° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 245/70R16 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4JK1 | Jiangxi ISUZU Engine Co., Ltd. | 100kW | 2499ml |
