| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9850,10200mm | ||
| Width | 2500mm | ||
| Height | 3500,3625,3760,3950mm | ||
| Curb Weight | 12500kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | Actros 1832E5, second-class, Daimler AG | ||
| Front/Rear Overhang | 1440/2710,1440/3060mm | ||
| Number of Leaf Springs | 2/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 5700mm | ||
| Axle Load | 7000/11000kg | ||
| Front Wheel Track | 2034mm | ||
| Rear Wheel Track | 1804mm | ||
| Approaching/Departuring Angle | 16/10,16/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| OM501LA.V/1 | Daimler AG | 240kW | 11946ml |
