| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6220,6415,6620mm | ||
| Width | 2385mm | ||
| Height | 3230,3350,3500,3650mm | ||
| Curb Weight | 7305kg | ||
| Gross Weight | 7500,7725,7955,8195,8490kg | ||
| Seats | 3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | U4000, second-class, Daimler AG | ||
| Front/Rear Overhang | 1050/1320,1050/1515,1050/1720mm | ||
| Number of Leaf Springs | -/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3850mm | ||
| Axle Load | 3700/3800,3820/3905,3900/4055,3850/4345,4000/4490kg | ||
| Front Wheel Track | 1927mm | ||
| Rear Wheel Track | 1927mm | ||
| Approaching/Departuring Angle | 41/23,41/22° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 365/80R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| OM924LA.V/2 | Daimler AG | 164kW | 4801ml |
