| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5910,5996mm | ||
| Width | 1993mm | ||
| Height | 2750,2920,3100,3250mm | ||
| Curb Weight | 2550kg | ||
| Gross Weight | 3550kg | ||
| Seats | 5-9 | ||
| Max Speed | 130km/h | ||
| Chassis | |||
| Chassis Model | FA5041XXY, Fujian Benz Automotive Co., Ltd. | ||
| Front/Rear Overhang | 1005/1240,1005/1326mm | ||
| Number of Leaf Springs | -/2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3665mm | ||
| Axle Load | 1700/1850kg | ||
| Front Wheel Track | 1700mm | ||
| Rear Wheel Track | 1718mm | ||
| Approaching/Departuring Angle | 19/18,19/17° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 235/65R16C | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 651955 | Daimler AG | 110kW | 2143ml |
