| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5990mm | ||
| Width | 2305mm | ||
| Height | 2575,2630,2725,2800,2900,3050,3150,3300mm | ||
| Curb Weight | 4295kg | ||
| Gross Weight | 4490,4445,4405kg | ||
| Seats | 3 | ||
| Max Speed | 130km/h | ||
| Chassis | |||
| Chassis Model | NJ1045EFC | ||
| Front/Rear Overhang | 998/1692mm | ||
| Number of Leaf Springs | -/7,-/3,-/1+- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 1610/2880,1590/2855,1570/2835kg | ||
| Front Wheel Track | 1725mm | ||
| Rear Wheel Track | 1538,1750mm | ||
| Approaching/Departuring Angle | 23.5/14.7° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 195/75R16LT 8PR,195/75R16LT 10PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1CE34818 | NAVECO Ltd. | 107kW | 2998ml |
