| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8815,9045mm | ||
| Width | 2540mm | ||
| Height | 2980mm | ||
| Curb Weight | 11450kg | ||
| Gross Weight | 16000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND1160AD5J6Z01 | ||
| Front/Rear Overhang | 1435/2880mm | ||
| Number of Leaf Springs | 9/9+6,13/8+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4100,4500,4800mm | ||
| Axle Load | 6000/10000kg | ||
| Front Wheel Track | 1985,1995mm | ||
| Rear Wheel Track | 1848,1800mm | ||
| Approaching/Departuring Angle | 15/12.7° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00R20 16PR,11.00R20 18PR,12.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP6.180E50 | Weifang Weichai Deutz Engine Co., Ltd. | 132kW | 6750ml |
| WP7.270E51 | Weichai Power Co., Ltd. | 199kW | 7470ml |
