| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5580mm | ||
| Width | 2000mm | ||
| Height | 2540,2790,3110mm | ||
| Curb Weight | 3340kg | ||
| Gross Weight | 4280kg | ||
| Seats | 3 | ||
| Max Speed | 130km/h | ||
| Chassis | |||
| Chassis Model | NJ6565DCM, Nanjing Automobile (Group) Corporation | ||
| Front/Rear Overhang | 1000/1270mm | ||
| Number of Leaf Springs | -/6,-/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3310mm | ||
| Axle Load | 1620/2660kg | ||
| Front Wheel Track | 1695mm | ||
| Rear Wheel Track | 1540mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50R16LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1CE34818 | NAVECO Ltd. | 107kW | 2998ml |
| SOFIM8140.47Z5 | NAVECO Ltd. | 90kW | 2499ml |
