| Basic Information | |||
| Usage | Road-block Removal Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11410mm | ||
| Width | 2500mm | ||
| Height | 3295mm | ||
| Curb Weight | 23500kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 102km/h | ||
| Chassis | |||
| Chassis Model | ZZ1317N4667E1B | ||
| Front/Rear Overhang | 1500/1280mm | ||
| Number of Leaf Springs | 11/11/12,4/4/12,11/11/-,4/4/- | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+4600+1350,1800+4575+1400,2150+4600+1350,2150+4575+1400mm | ||
| Axle Load | 6500/7000/17500(two axles)kg | ||
| Front Wheel Track | 2022/2022,2041/2041mm | ||
| Rear Wheel Track | 1830/1830mm | ||
| Approaching/Departuring Angle | 14/17° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 315/80R22.5 18PR/315/80R22.5 16PR,295/80R22.5,12R22.5,12.00R20 16PR,11.00R20,12.00-20 16PR,11.00-20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.28-50;D10.31-50;D10.34-50;D10.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 9726ml |
