| Basic Information | |||
| Usage | Street Sprinkler | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5225mm | ||
| Width | 1980,1921,1900mm | ||
| Height | 2285mm | ||
| Curb Weight | 2365kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2 | ||
| Max Speed | 88km/h | ||
| Chassis | |||
| Chassis Model | BJ3046D9JBA-FA | ||
| Front/Rear Overhang | 1100/1325mm | ||
| Number of Leaf Springs | 8/8+5,7/6+4 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2600,2800mm | ||
| Axle Load | 1800/2695kg | ||
| Front Wheel Track | 1500mm | ||
| Rear Wheel Track | 1530,1485,1490mm | ||
| Approaching/Departuring Angle | 27/18° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.50-16 8PR,7.00-16 10PR,7.50R16 8PR,7.00R16 10PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4B2-95C50 | Anhui Quanchai Power Co., Ltd. | 70kW | 2545ml |
| YN27CRE1 | Kunming Yunnei Power Co., Ltd. | 70kW | 2672ml |
