| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 4790mm | ||
| Width | 1520mm | ||
| Height | 2650mm | ||
| Curb Weight | 2480kg | ||
| Gross Weight | 2610kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | BJ1030V4JV4-F1 | ||
| Front/Rear Overhang | 895/1195mm | ||
| Number of Leaf Springs | 5/4,5/6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2700,2370mm | ||
| Axle Load | 1210/1400kg | ||
| Front Wheel Track | 1260mm | ||
| Rear Wheel Track | 1260,1340mm | ||
| Approaching/Departuring Angle | 24/18° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 175R14LT 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| LJ465Q-2AE | Liuzhou Wuling Liuji Power Co., Ltd. | 45kW | 1051ml |
| 4W12M1 | Foton Motor Co., Ltd. | 63kW | 1206ml |
