| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB 17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5875mm | ||
| Width | 2020mm | ||
| Height | 2750mm | ||
| Curb Weight | 4091kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2+3 | ||
| Max Speed | 99km/h | ||
| Chassis | |||
| Chassis Model | BJ1049V9AD6-A1 | ||
| Front/Rear Overhang | 1085/1430mm | ||
| Number of Leaf Springs | 7/4+5,3+1/6+7,3+1/5+4,7/6+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 2000/2495kg | ||
| Front Wheel Track | 1490,1530mm | ||
| Rear Wheel Track | 1425,1485mm | ||
| Approaching/Departuring Angle | 23/17° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50-16LT 12PR,6.50R16LT 12PR,7.00-16LT 8PR,7.00R16LT 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF2.8s5R117 | Beijng Foton Cummins Engine Corporation | 87kW | 2780ml |
| ISF2.8s5F117 | Beijing Foton Cummins Engine Corporation | 87kW | 2780ml |
| ISF2.8s5F129 | Beijing Foton Cummins Engine Corporation | 96kW | 2780ml |
| ISF2.8s5129T | Beijing Foton Cummins Engine Corporation | 96kW | 2780ml |
