| Basic Information |
| Usage |
Snow Sweeper |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
8530,8300mm |
| Width |
2550mm |
| Height |
3050mm |
| Curb Weight |
10220kg |
| Gross Weight |
18000kg |
| Seats |
2 |
| Max Speed |
101km/h |
| Chassis |
| Chassis Model |
ZZ1187M501GE1 |
| Front/Rear Overhang |
1660/2370,1430/2370mm |
| Number of Leaf Springs |
11/9+8,3/9+8,3/3+2,3/- |
| Number of Axles |
2 |
| Wheelbase |
3650,3800,4200,4500,4700,5000,5200mm |
| Axle Load |
6500/11500kg |
| Front Wheel Track |
1900,1950,2035mm |
| Rear Wheel Track |
1800,1860mm |
| Approaching/Departuring Angle |
19/12° |
| Tire |
| Number of Tires |
6 |
| Tire |
295/80R22.5,12R22.5,11.00R20,10.00R20 |
| Engine |
| Model |
MC05.21-50,MC07.21-50,MC07.24-50,MC07.28-50,MC07.24-52,MC07.28-52 |
| Power |
151,151,176,206,176,206kW |
| Brand |
China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement |
4580,6870,6870,6870,6870,6870ml |
