| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 6470,6850,7020mm | ||
| Width | 2300mm | ||
| Height | 2560mm | ||
| Curb Weight | 5940kg | ||
| Gross Weight | 9100kg | ||
| Seats | 3 | ||
| Max Speed | 103km/h | ||
| Chassis | |||
| Chassis Model | EQ1095SJ8CD2 | ||
| Front/Rear Overhang | 1130/2032mm | ||
| Number of Leaf Springs | 8/10+7,12/12+9 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3308,3800mm | ||
| Axle Load | 3300/5800kg | ||
| Front Wheel Track | 1745mm | ||
| Rear Wheel Track | 1586,1630, 1650,1800mm | ||
| Approaching/Departuring Angle | 21/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.50R16 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCY24140-60ZD30D16-6ND25TCIF1D30TCIF1NV30-C6GNV30-C6DD4.0NS6B160Q28-130E60 | Guangxi Yuchai Machinery Co., Ltd. | 103kW | 2360ml |
