| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB 17691-2005 national V emission standards, GB 3847-2005 | ||
| Length | 4705mm | ||
| Width | 1920mm | ||
| Height | 2230mm | ||
| Curb Weight | 2920kg | ||
| Gross Weight | 6495kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | HFC1060P73K1B2VZ | ||
| Front/Rear Overhang | 1110/1105mm | ||
| Number of Leaf Springs | 7/5+6,7/4+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2490mm | ||
| Axle Load | 2350/4145kg | ||
| Front Wheel Track | 1440mm | ||
| Rear Wheel Track | 1425mm | ||
| Approaching/Departuring Angle | 20.5/22° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 12PR ,7.00-16LT 12PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF2.8s5129T | Beijing Foton Cummins Engine Corporation | 96kW | 2780ml |
