| Basic Information | |||
| Usage | Aluminum Alloy Oil Tanker | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8730,9100,9300,9380mm | ||
| Width | 2515mm | ||
| Height | 3040mm | ||
| Curb Weight | 11100kg | ||
| Gross Weight | 16000kg | ||
| Seats | 3 | ||
| Max Speed | 101km/h | ||
| Chassis | |||
| Chassis Model | CA1160P62K1L2A1E5Z | ||
| Front/Rear Overhang | 1400/2830mm | ||
| Number of Leaf Springs | 10/12+8,13/12+8,12/12+8,12/10+9 | ||
| Number of Axles | 2 | ||
| Wheelbase | 5300,5000,4700,4500mm | ||
| Axle Load | 6000/10000kg | ||
| Front Wheel Track | 1914,1928,1800,1968,1952,1868mm | ||
| Rear Wheel Track | 1847,1860,1890,1878mm | ||
| Approaching/Departuring Angle | 21/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00-20,10.00R20,11R22.5,11.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| BF6M2012-22E51 | China FAW Group Corporation | 165kW | 6060ml |
| BF6M2012-20E51 | China FAW Group Corporation | 150kW | 6060ml |
| CA4DK1-22E51 | China FAW Group Corporation | 165kW | 4764ml |
| CA4DK1-18E51 | China FAW Group Corporation | 139kW | 4764ml |
| CA6DH1-22E5 | China FAW Group Corporation | 165kW | 5700ml |
| CA6DH1-22E51 | China FAW Group Corporation | 165kW | 5700ml |
