| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB14762-2008 national Ⅳ emission standards, GB18285-2005,GB11340-2005,GB14763-2005 | ||
| Length | 4710mm | ||
| Width | 1920mm | ||
| Height | 2130,2190mm | ||
| Curb Weight | 2280kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | BJ1051P1D22D | ||
| Front/Rear Overhang | 1020/1190mm | ||
| Number of Leaf Springs | 6/9 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2500mm | ||
| Axle Load | 2000/2495kg | ||
| Front Wheel Track | 1460mm | ||
| Rear Wheel Track | 1470mm | ||
| Approaching/Departuring Angle | 25/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50-16LT 10PR,6.50R16LT 10PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 491QMB | Shenyang Xinguang Huachen Automibile Engine Co., Ltd. | 82kW | 2237ml |
