| Basic Information | |||
| Usage | Suction-type Sewer Scavenger | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 4980mm | ||
| Width | 1900mm | ||
| Height | 2220mm | ||
| Curb Weight | 3035kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | BJ1041V9JD3-A1 | ||
| Front/Rear Overhang | 1095/1285mm | ||
| Number of Leaf Springs | 7/4+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2600mm | ||
| Axle Load | 1840/2655kg | ||
| Front Wheel Track | 1490mm | ||
| Rear Wheel Track | 1425mm | ||
| Approaching/Departuring Angle | 22/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50R16LT 12PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF2.8s5R117 | Beijing Foton Cummins Engine Corporation | 87kW | 2780ml |
| ISF2.8s5F117 | Beijing Foton Cummins Engine Corporation | 87kW | 2780ml |
