| Basic Information | |||
| Usage | Suction-type Sewer Scavenger | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 6460mm | ||
| Width | 2380mm | ||
| Height | 3110mm | ||
| Curb Weight | 6530kg | ||
| Gross Weight | 12490kg | ||
| Seats | 3 | ||
| Max Speed | 85km/h | ||
| Chassis | |||
| Chassis Model | DFL1120B3 | ||
| Front/Rear Overhang | 1430/1380mm | ||
| Number of Leaf Springs | 7/9+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3650,3800mm | ||
| Axle Load | 4930/7560kg | ||
| Front Wheel Track | 1880mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 20/21° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-20,8.25R20,9.00-20,9.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISDe160 40 | Dongfeng Cummins Engine Co., Ltd. | 118kW | 4500ml |
| ISDe180 40 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 4500ml |
| EQH180-40 | Dongfeng Trucks Co., Ltd. | 132kW | 4752ml |
| ISB180 40 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 5900ml |
