| Basic Information | |||
| Usage | Tree Sprinkling Tanker | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB14762-2008 national Ⅳ emission standards, GB18285-2005,GB11340-2005,GB14763-2005 | ||
| Length | 5180mm | ||
| Width | 1800mm | ||
| Height | 2140mm | ||
| Curb Weight | 2450kg | ||
| Gross Weight | 5490kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | CA1051E-4A | ||
| Front/Rear Overhang | 1023/1557mm | ||
| Number of Leaf Springs | 7/8+3,7/8+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2600mm | ||
| Axle Load | 2490/3000kg | ||
| Front Wheel Track | 1414mm | ||
| Rear Wheel Track | 1370mm | ||
| Approaching/Departuring Angle | 22/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50-16 12PR,7.00-16 10PR,6.50R16 12PR,7.00R16 10PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 491QMB | Shenyang Xinguang Huachen Automibile Engine Co., Ltd. | 82kW | 2237ml |
