| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB18285-2005,GB11340-2005 | ||
| Length | 6610mm | ||
| Width | 2245mm | ||
| Height | 2530mm | ||
| Curb Weight | 5600kg | ||
| Gross Weight | 8495kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | HFC1081P81N1C5VZ | ||
| Front/Rear Overhang | 1085/1710mm | ||
| Number of Leaf Springs | 9/6+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3815mm | ||
| Axle Load | 2495/6000kg | ||
| Front Wheel Track | 1665,1685mm | ||
| Rear Wheel Track | 1600mm | ||
| Approaching/Departuring Angle | 24/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-16 14PR,8.25R16 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YN38QNE | Kunming Yunnei Power Co., Ltd. | 95kW | 3762ml |
