| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11180,11580mm | ||
| Width | 2550mm | ||
| Height | 3900mm | ||
| Curb Weight | 11250kg | ||
| Gross Weight | 20400kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | BJ1203DLPHH-AA | ||
| Front/Rear Overhang | 1555/2965,1555/3365mm | ||
| Number of Leaf Springs | 3/3/4+3 | ||
| Number of Axles | 3 | ||
| Wheelbase | 1860+4800mm | ||
| Axle Load | 4800/4800/10800kg | ||
| Front Wheel Track | 1960/1960mm | ||
| Rear Wheel Track | 1860mm | ||
| Approaching/Departuring Angle | 14/8° | ||
| Tire | |||
| Number of Tires | 8 | ||
| Tire | 275/70R22.5 18PR,11R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 198 | Dongfeng Cummins Engine Co., Ltd. | 198kW | 6700ml |
| 221 | Dongfeng Cummins Engine Co., Ltd. | 6700ml | |
| 210 | Dongfeng Cummins Engine Co., Ltd. | 6700ml | |
