| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 9800mm | ||
| Width | 2500mm | ||
| Height | 3340mm | ||
| Curb Weight | 15060kg | ||
| Gross Weight | 31000kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | SX5316GJBJT326 | ||
| Front/Rear Overhang | 1525/1900mm | ||
| Number of Leaf Springs | 13/13/12,左14右13/左14右13/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3175+1400,1950+3025+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2036/2036mm | ||
| Rear Wheel Track | 1850/1850mm | ||
| Approaching/Departuring Angle | 20/17° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00-20 18PR,11.00R20 18PR,12.00-20 18PR,12.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISM11E4 345 | Xi'an Cummine Engine Co., Ltd. | 250kW | 10800ml |
| ISM11E4 385 | Xi'an Cummins Engine Co., Ltd. | 280kW | 10800ml |
