| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11180,11730mm | ||
| Width | 2550mm | ||
| Height | 3540,3600,3700,3800mm | ||
| Curb Weight | 10500kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | CQ1186TCLHMDG681 | ||
| Front/Rear Overhang | 1435/2770mm | ||
| Number of Leaf Springs | -/-,3/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 6795,6300mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 2020mm | ||
| Rear Wheel Track | 1858mm | ||
| Approaching/Departuring Angle | 12/7° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 315/70R22.5 16PR,315/60R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| SC7H245Q5 | SDEC Power | 180kW | 6440ml |
| SC7H260Q5 | SDEC Power | 192kW | 6440ml |
| SC7H280Q5 | SDEC Power | 205kW | 6440ml |
