| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 10960mm | ||
| Width | 2500mm | ||
| Height | 4000mm | ||
| Curb Weight | 12490kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | DFL1250A12 | ||
| Front/Rear Overhang | 1460/2850mm | ||
| Number of Leaf Springs | 8/9,8/10,9/10 | ||
| Number of Axles | 3 | ||
| Wheelbase | 5350+1300,5350+1350,5700+1300,5700+1350mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 1986,2040mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 18/10° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 10.00-20 18PR,10.00R20 18PR,11.00-20 18PR,11.00R20 16PR,295/80R22.5 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISDe245 40 | Dongfeng Cummins Engine Co., Ltd. | 180kW | 6700ml |
| ISDe270 40 | Dongfeng Cummins Engine Co., Ltd. | 198kW | 6700ml |
| ISC8.3-245E40A | Dongfeng Cummins Engine Co., Ltd. | 180kW | 8300ml |
| ISC8.3-270E40A | Dongfeng Cummins Engine Co., Ltd. | 198kW | 8300ml |
| ISC8.3-292E40A | Dongfeng Cummins Engine Co., Ltd. | 215kW | 8300ml |
