| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national V emission standards, GB3847-2005 | ||
| Length | 6620mm | ||
| Width | 2450mm | ||
| Height | 2800mm | ||
| Curb Weight | 5080kg | ||
| Gross Weight | 8275kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | BJ1089VEJEA-A2 | ||
| Front/Rear Overhang | 1095/1725mm | ||
| Number of Leaf Springs | 3+1/6+7,9/11+7,3/7+6,3/8+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360,3800mm | ||
| Axle Load | 3000/5275kg | ||
| Front Wheel Track | 1730,1685,1590mm | ||
| Rear Wheel Track | 1590,1615,1485mm | ||
| Approaching/Departuring Angle | 22/17° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.50-16LT 14PR,7.50R16LT 14PR,8.25-16LT 14PR,8.25R16LT 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF3.8s5154 | Beijing Foton Cummins Engine Corporation | 115kW | 3760ml |
| ISF3.8s5141 | Beijing Foton Cummins Engine Corporation | 105kW | 3760ml |
| ISF3.8E6154 | Beijing Foton Cummins Engine Corporation | 115kW | 3760ml |
