| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 4730mm | ||
| Width | 1780mm | ||
| Height | 2630mm | ||
| Curb Weight | 1560kg | ||
| Gross Weight | 2550kg | ||
| Seats | 2 | ||
| Max Speed | 115km/h | ||
| Chassis | |||
| Chassis Model | BJ1036V5JV5-D1 | ||
| Front/Rear Overhang | 605/1055mm | ||
| Number of Leaf Springs | -/5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3070,3170mm | ||
| Axle Load | 700/1850kg | ||
| Front Wheel Track | 1338mm | ||
| Rear Wheel Track | 1375,1405,1455mm | ||
| Approaching/Departuring Angle | 39/20° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 175R14LT 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| LJ469Q-1AE9 | Liuzhou Wuling Liuji Power Co., Ltd. | 64kW | 1249ml |
| 4W12M1 | Foton Motor Co., Ltd. | 63kW | 1206ml |
| DAM15R | Harbin Dong'an Auto Engine Co., Ltd. | 82kW | 1498ml |
