| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11380,11000,10000,9500mm | ||
| Width | 2500mm | ||
| Height | 3100mm | ||
| Curb Weight | 14040kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 93km/h | ||
| Chassis | |||
| Chassis Model | CA3310P1K2L3T4BE5A80 | ||
| Front/Rear Overhang | 1375/3105,2925,2175,1925mm | ||
| Number of Leaf Springs | 12/12/10,3/3/10,10/10/10,3/3/4,4/4/5,4/4/10 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1900+3200+1350,1900+3450+1350,1900+3650+1350,1900+2950+1350,1900+3050+1350,1900+2950+1300mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 1950/1950,2020/2020,1964/1964mm | ||
| Rear Wheel Track | 1847/1847,1860/1860,1878/1878,1890/1890mm | ||
| Approaching/Departuring Angle | 21/11,12,14,15° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 10.00-20,10.00R20,11.00-20,11.00R20,12R22.5 16PR,11R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA6DL1-32E5 | China FAW Group Corporation | 238kW | 7700ml |
| WP10.270E53 | Weichai Holding Group Co., Ltd. | 199kW | 9726ml |
| WP10.310E53 | Weichai Holding Group Co., Ltd. | 228kW | 9726ml |
| CA6DL1-29E5 | China FAW Group Corporation | 216kW | 7700ml |
| WP10.350E53 | Weichai Holding Group Co., Ltd. | 257kW | 9726ml |
| WP10H375E50 | Weichai Holding Group Co., Ltd. | 276kW | 9500ml |
| WP8.340E51 | Weichai Holding Group Co., Ltd. | 250kW | 7800ml |
| CA6DL3-37E5 | China FAW Group Corporation | 279kW | 8600ml |
