| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8600,9000,9300,9700mm | ||
| Width | 2500mm | ||
| Height | 3050mm | ||
| Curb Weight | 6460kg | ||
| Gross Weight | 16000kg | ||
| Seats | 2,3 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | HFC5161XXYP3K1A47V | ||
| Front/Rear Overhang | 1400/2500,1400/2600mm | ||
| Number of Leaf Springs | 3/4+3,3/9+7,9/9+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4700,5000,5700,5300mm | ||
| Axle Load | 5600/10400kg | ||
| Front Wheel Track | 1800,1820,1870,1920,1960mm | ||
| Rear Wheel Track | 1800,1860mm | ||
| Approaching/Departuring Angle | 18/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00R20 16PR,10R22.5 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP4.165E50 | Weichai (Weifang) Medium Deisel Co., Ltd. | 121kW | 4500ml |
| YC4EG185-50 | Guangxi Yuchai Machinery Co., Ltd. | 136kW | 4730ml |
| WP4.1Q160E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 115kW | 4088ml |
| YC4S160-50 | Guangxi Yuchai Machinery Co., Ltd. | 118kW | 3767ml |
| JND412D190-52 | Anhui JAC Navistar Diesel Co., Ltd. | 140kW | 4748ml |
| YNF40E1 | Kunming Yunnei Power Co., Ltd. | 125kW | 3920ml |
| D45TCIE2 | Kunming Yunnei Power Co., Ltd. | 147kW | 4460ml |
| D45TCIE1 | Kunming Yunnei Power Co., Ltd. | 162kW | 4460ml |
