| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8600,9000,9600mm | ||
| Width | 2550mm | ||
| Height | 3050mm | ||
| Curb Weight | 6650kg | ||
| Gross Weight | 18000kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | QCC1182D651N-E | ||
| Front/Rear Overhang | 1450/2550mm | ||
| Number of Leaf Springs | 7/9+6,8/9+6,8/10+8,9/10+6,9/10+3,3/4+3,9/11+8,9/10+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4600,5000,5600mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1940mm | ||
| Rear Wheel Track | 1860mm | ||
| Approaching/Departuring Angle | 23/17° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00R20,11R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC4EG160-50 | Guangxi Yuchai Machinery Co., Ltd. | 118kW | 4730ml |
| YC4EG185-50 | Guangxi Yuchai Machinery Co., Ltd. | 136kW | 4730ml |
| WP6.180E50 | Weichai (Weifang) Medium Diesel Co., Ltd. | 132kW | 6750ml |
| YC6JA180-50 | Guangxi Yuchai Machinery Co., Ltd. | 132kW | 6870ml |
| WP6.220E50 | Weichai (Weifang) Medium Diesel Co., Ltd. | 162kW | 6750ml |
