| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 7150,6770,6570mm | ||
| Width | 2330mm | ||
| Height | 2780mm | ||
| Curb Weight | 5900kg | ||
| Gross Weight | 8495kg | ||
| Seats | 2,3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | EQ1082GLJ | ||
| Front/Rear Overhang | 1070/1700,1070/1750,1070/1850,1070/1580,1250/2020mm | ||
| Number of Leaf Springs | 9/9+5,8/11+8,8/10+8,9/11+8,11/9+7,8/10+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300,3650,3800,3950,4500mm | ||
| Axle Load | 3400/5095kg | ||
| Front Wheel Track | 1750,1770mm | ||
| Rear Wheel Track | 1586,1650mm | ||
| Approaching/Departuring Angle | 22/14,22/13,22/12,22/12,20/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-16LT 14PR,8.25R16LT 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CY4BK251 | Dongfeng Chaoyang Diesel Co., Ltd. | 96kW | 3856ml |
| 4DX23-140E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Plant | 105kW | 3857ml |
| YC4S150-50 | Guangxi Yuchai Machinery Co., Ltd. | 110kW | 3767ml |
