| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
5180mm |
| Width |
1980,2040mm |
| Height |
2350mm |
| Curb Weight |
3350kg |
| Gross Weight |
4495kg |
| Seats |
2,3 |
| Max Speed |
95km/h |
| Chassis |
| Chassis Model |
KMC1041A28D5 |
| Front/Rear Overhang |
1130/1250mm |
| Number of Leaf Springs |
9/8+4,3/5+3 |
| Number of Axles |
2 |
| Wheelbase |
2800,3100,3300mm |
| Axle Load |
1610/2885kg |
| Front Wheel Track |
1495mm |
| Rear Wheel Track |
1490mm |
| Approaching/Departuring Angle |
20/23° |
| Tire |
| Number of Tires |
6 |
| Tire |
6.50-16LT 10PR,6.50R16LT 10PR,7.00-16LT 8PR,7.00R16LT 8PR |
| Engine |
| Model |
WP2.1Q82E50,D19TCIE1,YN27CRE1,SD4D25R-70,4DW93-84E5,YCD4N4S-110,WP2.3Q110E50,CA4DB1-11E5 |
| Power |
60,75,70,70,64,80,81,80kW |
| Brand |
Weichai Power Yangzhou Diesel Co., Ltd.;Kunming Yunnei Power Co., Ltd.;Kunming Yunnei Power Co., Ltd.;Jiangsu Sida Power Machinery Group Co., Ltd.;FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant;Guangxi Yuchai Machinery Co., Ltd.;Weichai Power Yangzhou Diesel Co., Ltd.;FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant |
| Displacement |
2088,1910,2672,2545,2540,2799,2290,2200ml |
