| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2250mm | ||
| Height | 3050mm | ||
| Curb Weight | 3350kg | ||
| Gross Weight | 4495kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | BJ1043V9JEA-J7 | ||
| Front/Rear Overhang | 1150/1485,1130/1505mm | ||
| Number of Leaf Springs | 4/6+7,10/9+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 1800/2695kg | ||
| Front Wheel Track | 1715,1550,1730mm | ||
| Rear Wheel Track | 1630,1590,1800mm | ||
| Approaching/Departuring Angle | 21/15,21/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16 8PR,7.50R16 6PR,8.25R16 6PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF3.8s5141 | Beijing Foton Cummins Engine Corporation | 105kW | 3760ml |
| ISF2.8s5129T | Beijing Foton Cummins Engine Corporation | 96kW | 2780ml |
| 4B2-115C50 | Anhui Quanchai Power Co., Ltd. | 85kW | 2545ml |
| CA4DC3-12E5 | Deutz FAW (Dalian) Diesel Co., Ltd. | 91kW | 3000ml |
| D25TCIE1 | Kunming Yunnei Power Co., Ltd. | 105kW | 2499ml |
| CY4BK351 | Dongfeng Chapyang Diesel Co., Ltd. | 91kW | 3856ml |
| YN38CRE1 | Kunming Yunnei Power Co., Ltd. | 95kW | 3760ml |
| 4J28TC3 | Foton Motor Co., Ltd. | 81kW | 2771ml |
| YN33CRE1 | Kunming Yunnei Power Co., Ltd. | 85kW | 3298ml |
| CY4BK551 | Dongfeng Chaoyang Diesel Co., Ltd. | 75kW | 3707ml |
| 4B2-110C55 | Anhui Quanchai Power Co., Ltd. | 80kW | 2545ml |
| ISF2.8s5148T | Beijing Foton Cummins Engine Corporation | 110kW | 2780ml |
| NGD3.0-CS5D | Dongfeng Chaoyang Diesel Co., Ltd. | 115kW | 2968ml |
