| Basic Information |
| Usage |
Delivery Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
11850mm |
| Width |
2500mm |
| Height |
3454mm |
| Curb Weight |
14805kg |
| Gross Weight |
31000kg |
| Seats |
2,3 |
| Max Speed |
89km/h |
| Chassis |
| Chassis Model |
CA1310P63K1L6T4E5 |
| Front/Rear Overhang |
1400/2600mm |
| Number of Leaf Springs |
10/10/11,3/3/11,3/3/4,9/9/10,3/3/10 |
| Number of Axles |
4 |
| Wheelbase |
1950+4550+1350,1950+3550+1350mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
1950/1950mm |
| Rear Wheel Track |
1847/1847,1878/1878,1988/1988mm |
| Approaching/Departuring Angle |
21/11° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00R20 ,10.00R20 ,11R22.5 ,295/80R22.5,12R22.5 |
| Engine |
| Model |
CA6DK1-32E5,CA6DL1-28E5,CA6DK1-32E51,CA6DL1-32E5,CA6DL2-35E5 |
| Power |
239,209,239,238,261kW |
| Brand |
China FAW Corporation Group;China FAW Corporation Group;China FAW Corporation Group;China FAW Corporation Group;China FAW Corporation Group |
| Displacement |
7146,7700,7146,7700,8600ml |
