| Basic Information |
| Usage |
Delivery Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
10800mm |
| Width |
2500mm |
| Height |
3150mm |
| Curb Weight |
10205kg |
| Gross Weight |
25000kg |
| Seats |
3 |
| Max Speed |
89km/h |
| Chassis |
| Chassis Model |
CA1250P62K1L7T3E5 |
| Front/Rear Overhang |
1400/2800mm |
| Number of Leaf Springs |
11/11/13+7,3/3/10+9,3/3/4+3,3/3/12+9,10/10/12+9 |
| Number of Axles |
3 |
| Wheelbase |
1900+4700,1900+4300mm |
| Axle Load |
6650/6850/11500kg |
| Front Wheel Track |
1800/1800,1900/1900,1928/1928,1952/1952mm |
| Rear Wheel Track |
1860mm |
| Approaching/Departuring Angle |
18/12° |
| Tire |
| Number of Tires |
8 |
| Tire |
11.00R20,12R22.5,295/80R22.5 |
| Engine |
| Model |
BF6M2012-22E5,CA4DK1-22E5,CA6DK1-24E5,CA6DH1-24E5,CA6DK1-28E5,CA6DH1-25E51 |
| Power |
165,165,180,179,209,186kW |
| Brand |
China FAW Group Corporation;China FAW Group Corporation;China FAW Group Corporation;China FAW Group Corporation;China FAW Group Corporation;China FAW Group Corporation |
| Displacement |
6060,4764,7146,5700,7146,5700ml |
