| Basic Information | |||
| Usage | Tree Sprinkling Tanker | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8400,8200mm | ||
| Width | 2480mm | ||
| Height | 3000mm | ||
| Curb Weight | 7300kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2,3 | ||
| Max Speed | 101km/h | ||
| Chassis | |||
| Chassis Model | CA1180P62K1L2A1E5Z | ||
| Front/Rear Overhang | 1400/2300mm | ||
| Number of Leaf Springs | 10/12+8,13/12+8,12/12+8,12/10+9,9/12+8,7/7+6,3/7+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 5800,5300,5000,4700,4500,4200,4000,3800mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1914,1827,1952,1968,1868mm | ||
| Rear Wheel Track | 1847,1860,1878mm | ||
| Approaching/Departuring Angle | 21/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10.00R20 18PR,11.00R20,12R22.5,275/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA4DK1-22E51 | China FAW Group Corporation | 165kW | 4764ml |
| CA4DK1-18E51 | China FAW Group Corporation | 139kW | 4764ml |
| CA6DK1-26E51 | China FAW Group Corporation | 195kW | 7146ml |
| CA6DH1-22E5 | China FAW Group Corporation | 165kW | 5700ml |
| CA6DH1-22E51 | China FAW Group Corporation | 165kW | 5700ml |
| CA6DH1-24E5 | China FAW Group Corporation | 179kW | 5700ml |
| CA4DK1-18E5 | China FAW Group Corporation | 139kW | 4764ml |
| CA4DK1-22E5 | China FAW Group Corporation | 165kW | 4764ml |
