| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
14500,14200,13900mm |
| Width |
2550mm |
| Height |
4000mm |
| Curb Weight |
43870kg |
| Gross Weight |
44000kg |
| Seats |
2 |
| Max Speed |
90km/h |
| Chassis |
| Chassis Model |
ZZ5446V516ME1 |
| Front/Rear Overhang |
1475/3475mm |
| Number of Leaf Springs |
4/4/5,11/11/5,11/11/12 |
| Number of Axles |
4 |
| Wheelbase |
1950+4500+1400,1950+4525+1350,1950+4800+1400,1950+4825+1350,1950+5100+1400,1950+5125+1350,1950+5425+1350mm |
| Axle Load |
9000/9000/13000/13000kg |
| Front Wheel Track |
2110/2110mm |
| Rear Wheel Track |
1830/1830mm |
| Approaching/Departuring Angle |
18/11° |
| Tire |
| Number of Tires |
12 |
| Tire |
385/65R22.5/315/80R22.5,385/65R22.5/12.00R20 |
| Engine |
| Model |
MC11.40-50,MC11.44-50,MC13.48-50,MC13.54-50 |
| Power |
297,327,356,400kW |
| Brand |
China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement |
10518,10518,12419,12419ml |
