| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10230mm | ||
| Width | 2540mm | ||
| Height | 3850mm | ||
| Curb Weight | 19350kg | ||
| Gross Weight | 19545kg | ||
| Seats | 3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | EQ1256GFJ1 | ||
| Front/Rear Overhang | 1450/2580,1250/2780mm | ||
| Number of Leaf Springs | 9/9/10+8 | ||
| Number of Axles | 3 | ||
| Wheelbase | 1850+4350,1950+4250mm | ||
| Axle Load | 5800/5800/7945kg | ||
| Front Wheel Track | 1920/1920,1980/1980mm | ||
| Rear Wheel Track | 1860mm | ||
| Approaching/Departuring Angle | 20/18,20/17° | ||
| Tire | |||
| Number of Tires | 8 | ||
| Tire | 11.00R20,295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6JA220-50 | Guangxi Yuchai Machinery Co., Ltd. | 162kW | 6870ml |
| ISB210 50 | Dongfeng Cummins Engine Co., Ltd. | 155kW | 5900ml |
| ISB220 50 | Dongfeng Cummins Engine Co., Ltd. | 162kW | 5900ml |
