| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 5995mm | ||
| Width | 2190mm | ||
| Height | 3100,3250mm | ||
| Curb Weight | 4300kg | ||
| Gross Weight | 4495kg | ||
| Seats | 3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | ZB1040JDD6L | ||
| Front/Rear Overhang | 1140/1495mm | ||
| Number of Leaf Springs | 6/9+5,3/5+5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 1800/2695kg | ||
| Front Wheel Track | 1650mm | ||
| Rear Wheel Track | 1600mm | ||
| Approaching/Departuring Angle | 19/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 8PR,7.00R16LT 10PR,7.50R16LT 6PR,7.50R16LT 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP2.3NQ130E61 | Weichai Power Co., Ltd. | 96kW | 2289ml |
| D30TCIF1 | Kunming Yunnei Powet Co., Ltd. | 125kW | 2977ml |
| Q28-130E60 | Anhui Quanchai Power Co., Ltd. | 96kW | 2800ml |
