| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 5995mm | ||
| Width | 2030mm | ||
| Height | 2980mm | ||
| Curb Weight | 4300kg | ||
| Gross Weight | 4495kg | ||
| Seats | 3 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | CA1040P40K61L2BE6A84 | ||
| Front/Rear Overhang | 1115/1580mm | ||
| Number of Leaf Springs | 3/3+3,3/7+3,7/7+3,7/10+3,3/7+9,3/10+4,7/10+3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 1950/2545kg | ||
| Front Wheel Track | 1580,1600,1662,1761mm | ||
| Rear Wheel Track | 1480,1525,1565,1590mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50R16 12PR,7.00R16 8PR,7.50R16 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP2.3NQ120E61 | Weichai Power Co., Ltd. | 88kW | 2289ml |
| WP2.3NQ130E61 | Weichai Power Co., Ltd. | 96kW | 2289ml |
