| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5995mm | ||
| Width | 2150mm | ||
| Height | 3050mm | ||
| Curb Weight | 4300kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2,3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | ZZ1047F3315E145 | ||
| Front/Rear Overhang | 1160/1555mm | ||
| Number of Leaf Springs | 3/5+3,8/9+6,11/9+7,9/12+9,11/11+7,3/3+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3280,3160mm | ||
| Axle Load | 1790/2705kg | ||
| Front Wheel Track | 1605,1805mm | ||
| Rear Wheel Track | 1555,1595,1796mm | ||
| Approaching/Departuring Angle | 19/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 8PR,7.50R16LT 6PR,8.25R16LT 6PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YN27CRE1 | Kunming Yunnei Power Co., Ltd. | 70kW | 2672ml |
| YN38CRE1 | Kunming Yunnei Power Co., Ltd. | 95kW | 3760ml |
| CY4BK151 | Dongfeng Chaoyang Diesel Co., Ltd. | 105kW | 3856ml |
| JE493ZLQ5 | Jiangxi ISUZU Engine Co., Ltd. | 85kW | 2771ml |
| D25TCIE1 | Kunming Yunnei Power Co., Ltd. | 105kW | 2499ml |
| D25TCIE3 | Kunming Yunnei Power Co., Ltd. | 92kW | 2499ml |
| CA4D30C5-2B | Changchun FAW Sihuan Engine Manufacture Co., Ltd. | 100kW | 2896ml |
| YN27CRE10 | Kunming Yunnei Power Co., Ltd. | 85kW | 2672ml |
| D30TCIE1 | Kunming Yunnei Power Co., Ltd. | 115kW | 2977ml |
