| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 5510mm | ||
| Width | 2089mm | ||
| Height | 2940mm | ||
| Curb Weight | 3240kg | ||
| Gross Weight | 3370kg | ||
| Seats | 2 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | SY1037AADX9LEA | ||
| Front/Rear Overhang | 580/1530,580/1680mm | ||
| Number of Leaf Springs | 5/5+1 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3250,3400mm | ||
| Axle Load | 1450/1920kg | ||
| Front Wheel Track | 1450mm | ||
| Rear Wheel Track | 1415mm | ||
| Approaching/Departuring Angle | 30/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 185R14LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4A13L | Mianyang Xinchen Engine Co., Ltd. | 65kW | 1298ml |
| 4A15L | Mianyang Xinchen Engine Co., Ltd. | 75kW | 1495ml |
