| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11500mm | ||
| Width | 2500mm | ||
| Height | 3980mm | ||
| Curb Weight | 49870kg | ||
| Gross Weight | 50000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ZZ5507N31B7E1 | ||
| Front/Rear Overhang | 1500/2250mm | ||
| Number of Leaf Springs | 11/11/-/12 | ||
| Number of Axles | 5 | ||
| Wheelbase | 1950+3075+1375+1350,1950+4575+1375+1350mm | ||
| Axle Load | 8000/8000/8000/13000/13000kg | ||
| Front Wheel Track | 2022/2022/2022mm | ||
| Rear Wheel Track | 1830/1830mm | ||
| Approaching/Departuring Angle | 14/12° | ||
| Tire | |||
| Number of Tires | 14 | ||
| Tire | 12.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.38-50 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
