| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 10490mm | ||
| Width | 2480mm | ||
| Height | 3304,3404,3550mm | ||
| Curb Weight | 12900kg | ||
| Gross Weight | 14000kg | ||
| Seats | 4-10 | ||
| Max Speed | 120km/h | ||
| Chassis | |||
| Chassis Model | XMQ6100R2 | ||
| Front/Rear Overhang | 1975/3065mm | ||
| Number of Leaf Springs | 7/10,3/3,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 5450mm | ||
| Axle Load | 4300/9700kg | ||
| Front Wheel Track | 1920,2054,2054mm | ||
| Rear Wheel Track | 1800,1840,1850mm | ||
| Approaching/Departuring Angle | 10/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6L260-42 | Guangxi Yuchai Machinery Co., Ltd. | 191kW | 8424ml |
| YC6J245-42 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6494ml |
| ISBE4+250 | Cummmins Co., Ltd. | 184kW | 6700ml |
| WP7.270E40 | Weichai Power Co., Ltd. | 199kW | 7140ml |
| J08E-VK | Shanghai Hino Engine Co., Ltd. | 202kW | 7684ml |
| ISDe245 40 | Dongfeng Cummins Engine Co., Ltd. | 180kW | 6700ml |
