| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11900,11290mm | ||
| Width | 2550mm | ||
| Height | 3800mm | ||
| Curb Weight | 10010kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2,3 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | CA1180P1K2L6BE5A80 | ||
| Front/Rear Overhang | 1375/3725,1375/3515mm | ||
| Number of Leaf Springs | 3/2+-,3/3/4+3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 6400,6800mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1964mm | ||
| Rear Wheel Track | 1860mm | ||
| Approaching/Departuring Angle | 21/7,21/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 315/70R22.5 16PR,315/60R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA6DK1-32E5 | China FAW Group Corporation | 239kW | 7146ml |
| CA6DL1-32E5 | China FAW Group Corporation | 238kW | 7700ml |
